Description

Type 1 / Type 12:
The Voltmeter Resolution: ±0.1V
The Voltmeter Digital Display Range: 0v-40v
The Voltmeter Input Voltage Range: Dc 4v-40v
Output Voltage: Continuous Adjustable (1.3v-37 V)
Output Current: 2a
size :65*35mm
Led Digital Voltmeter Tube, The Accuracy Is Adjustable Function, Can Be Aimed At Your Multimeter Adjustable Accurate.
Press the key “S1” to let the display show the input or output voltage. when the green led light, it shows output, the red show input.
Note:
To guarantee the accuracy of the voltmeter , make sure the input voltage above 4V.
The input voltage must be 1.5v higher than the output voltage or 1.5v above.

Type 2 / Type 3 / Type 4:
Name : LM2596 DC-DC Buck module
Input voltage :4V ~ 35V
The output voltage : 1.23V ~ 30V
Output Current :3A( Max)
Conversion efficiency:92%( MAX )
Output ripple: <30mV
Switching frequency: 150KHz
Working temperature: -forty Five~ +85
Size :43mm * 21mm * 14mm(Long*Width*Hight)

Type 5 / Type 10 :
Module Properties: non-isolated constant current and voltage module
Rectification: non-synchronous rectification
Input voltage: 7V-35V
Output voltage: 1.25V-30V
Output current: adjustable maximum 3A
Conversion efficiency: 92% (the highest)
Switching frequency: 150KHz
Output ripple: 50mV (max) 20M bandwidth
Load Regulation: ± 0.5%
Voltage Regulation: ± 2.5%
Operating Temperature: -40 ° to +85 °
Weight:14 g
Size:46mmx23mmx10mm


Type 6:
Module chip: LM2596HVS(It is a higher version of LM2576HV LM2576.)

Input voltage range: 5V-60V (rated Suggestions below 50V reliable)

Output voltage range: 1.25V-26V

Output current: 3A(MAX)-need to add heat sink

Continuous working current: 1.2A (total power output within 20W)

Conversion efficiency: Up to 92% (output voltage higher, the higher the efficiency)

Switching Frequency: 150KHz

Rectifier: Non-Synchronous Rectification

Module Properties: Non-isolated step-down module (buck)

Short circuit protection: current limiting, since the recovery

Operating temperature: Industrial grade (-40 to +85) (output power 10W or less)

Full load temperature rise: 40

Load regulation: ±0.5%

Voltage regulation: ±0.5%

Dynamic response speed: 5% 200uS

Mode of connection:welding

<span style="color: rgb(34, 34, 3

Weight 0.03 kg
Dimensions 13 × 8 × 5 cm
