HC-SR04 HC-SR04P HC-SR04+ Ultrasonic Wave Detector Ranging Module HC SR04 HCSR04 Distance Sensor Ultrasonic Accessories Description: Module main technical parameters: 1.Working Voltage : 5V(DC) 2.Static current: Less than 2mA. 3.Output signal: Electric frequency signal, high level 5V, low level 0V. 4.Sensor angle: Not more than 15 degrees. 5.Detection distance: 2cm-450cm. 6.High precision: Up to 0.3cm 7.Input trigger signal: 10us TTL impulse 8.Echo signal : output TTL PWL signal Mode of connecti

Category:

HC-SR04 HC-SR04P HC-SR04+ Ultrasonic Wave Detector Ranging Module HC SR04 HCSR04 Distance Sensor Ultrasonic Accessories

Description:

Module main technical parameters:
1.Working Voltage : 5V(DC)
2.Static current: Less than 2mA.
3.Output signal: Electric frequency signal, high level 5V, low level 0V.
4.Sensor angle: Not more than 15 degrees.
5.Detection distance: 2cm-450cm.
6.High precision: Up to 0.3cm
7.Input trigger signal: 10us TTL impulse
8.Echo signal : output TTL PWL signal
Mode of connection:
1.VCC
2.trig(T)
3.echo(R)
4.GND
Use method:
Supply module with 5V, the output will be 5V while obstacle in range, or 0V if not.The out pin
of this module is used as a switching output when anti-theft module, and without the feet when
ranging modules.
Note : the module should be inserted in the circuit before been power, which avoid producing
high level of misoperation;if not, then power again.

Package Included:

1 Pcs Ultrasonic Module

Weight 0.02 kg
Dimensions 13 × 8 × 5 cm
Model

Type 4, Type 1, Type 2, Type 3, Type 5
