40A DC 9-50V Motor Speed Controller 2000W Voltage Regulator Dimming Dimmers Motor Speed Control Thermostat Electronic Module 12V

12V 24V 48V 200HZ 2000W MAX 10-50V 40A DC Motor Speed Control PWM HHO RC Controller

Description

Universal for various types of general-purpose DC brush motor speed
Various types of automotive motor speed (automotive cooling fan speed, automotive fan speed, car wiper motor speed, automotive air conditioning fan speed)
Production line conveyor speed, pipe exhaust fan speed, treadmill speed, multiple computer fan parallel speed, electronic fan speed
Various types of DC lamp dimming, all kinds of DC heater thermostat.
Specification:
Brand new
Working Voltage DC 9V-DC 50V
Control power
0.01-2000W (Max. rated current 40A):

for working voltage 12V : 12V*40A =480W
for working voltage 24v: 24V*40A=960W
for working voltage 36V:40V*40A=1600W
for working voltage 50V: 50V*40A=2000W
Quiescent current 0.025A
PWM duty cycle 5% -100%
PWM frequency 12khz
Operating temperature -20 – 40℃
Size
90*81*30 mm
speed controller

Package Included

1 Pcs PWM 2000W 40A Module
